AN AERO GRAVEL BIKE?
Aerodynamics always count. Gravel races often exceed 200km, with speeds reaching 70km/h, every watt saved brings us a little bit closer to victory.

FORK FLAP
Fork Flap: Stabilises the flow of air on the front end and greatly improves the aerodynamic penetration coefficient.

FLAT BACK PROFILE
Derived from the DOGMA, this profile reduces aerodynamic drag on the tube, especially when there are bottles present.

TICR
The complete integration of all cables offers aerodynamic improvement and allows for greater ease when loading bags.

GRAVEL GEOMETRY
Differentiated geometry and rake ensures the same trail and the same control across all frame sizes.

• Reach and stack: Compared to a traditional road bike, the GREVIL F has shorter reach and higher stack to create an elongated position, offering better comfort and better handling
• An increased seat tube angle allows for greater wheel clearance
• Modified fork angle and Rake ensures better handling and riding comfort
• Chain stays: Measuring between 422-425mm. This provides the best compromise between responsiveness and comfort. Compatible with 700c or 650b wheels.

TWIN ARMS
Maximum energy transmission and vibration absorption
The right chain stay is rotated downwards, as is the right seat stay, to have both rear triangles symmetrical with a uniform response to pedal strokes. Different connection points for the seat stays allows the seat tube to absorb impacts coming from the rear wheel in a more uniform way.

CARBON T900 UD
The right balance between reactivity, dampening capabilities and lightness for competition.

FRAME SET

FRAME
TorayCa T700 UD, TiCR cable routing, Italian BB

FORK
grevil onda fork with forkflap, tapered head tube

DRIVETRAIN

CRANKSET AND CHAINRINGS
Campagnolo Ekar 13s 1X

REAR DERAILLEUR
Campagnolo Ekar 13S

CASSETTE
Campagnolo Ekar 13S

CHAIN
Campagnolo Ekar C13 C-link 13s

BOTTOM BRACKET
Campagnolo Ekar 13S

BRAKES

FRONT BRAKE DISC
Campagnolo Ekar Ergopower 2 pistons, 160mm rotor

REAR BRAKE DISC
Campagnolo Ekar Ergopower 2 pistons, 160mm rotor

COCKPIT

HANDLEBAR
Jaguar GR Di2

STEM
Tiger Aero Alu TiCR

BAR TAPE
MOST Ultragrip Evo 3mm - Black

SADDLE
Most Lynx Aircross FEC Alloy Large 145mm

SEATPOST
Pinarello Aero Seatpost

WHEELS AND TIRES

WHEELSET DISC
Fulcrum Rapid Red 500

AXLES DISC
MOST Ultralight Custom Axle 12x100 & 12x142, Tool-free removal
